The practical application of the slide valve and link motion to stationary, portable, locomotive, and marine engines : with new and simple methods for proportioning the parts (1870)
Auchincloss, W. S. (William Stuart), 1842-1928 · New York : Van Nostrand · leaf 40
re would be required an angular advanceof 20° and a lap equivalent to the distance these degreesremove the eccentric centre from the line at right angles tothe crank; for a cut-off of 160°, an advance of 10° with acorresponding lap, and so on; the exhaust closure takingplace respectively at the… … w FIGURE 5 *
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
