Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 137
Cathode Electrolyte Fig. 93 … Fig. 94 electrolytic cell is shown in Fig. 93. The gas liberated atthe two electrodes in this case passes off into the air. Thevoltameter, however, can be so constructed that the liberatedgas will collect in an enclosed U-shaped tube, as shown inFig. 94. The direction of the current in the circuit…
Electrical engineering
