Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 16
ydraulic problem, but willserve to illustrate the relation between the electrical quan-tities that are to be discussed in one of the following sections. 4. Electrical Circuit Compared with Hydraulic Circuit.—In the electrical circuit, as indicated in Fig. 3, there is asource of electrical pressure,… … Fig. 3 while the electric motor (M), in Fig. 3, corresponds to thewater motor referred to in the example under section (3). Ifall the electrical pressure is consumed in causing a givenquantity of electricity to flow through the wire in a giventime, there will be no pressure available to operate the…
Electrical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
