iron core similar to a trans-former core. For a two-phase starter only two coils arenecessary. These coils are provided with a number of taps,so that the compensator may be adjusted for different start-ing requirements. The switch is shown in the startingposition, and by following out the… … Pig. 23. starting position. The E. M. F. developed in that portionof the coil between / and the adjustable contact o opposes,and hence decreases, the line voltage and allows the motorto start up gradually. After the motor is under headway, theswitch is thrown up to the running position and one…
