Hawkins electrical guide. Questions, answers & illustrations; a progressive course of study for engineers, electricians, students and those desiring to acquire a working knowledge of electricity and its applications; a practical treatise (1914)
Hawkins, N. (Nehemiah), 1833- · New York, T. Audel · leaf 147
SCHEME OF 3 PHASE NO VOLTAGE CONNECTIONS TO RESPECTIVE MAINS ON GENERATOR SIDE OF APPARATUS … Fig. 2,336 and 2.337.— Diagramshowing three phase no voltageconnections for I-T-E circuitbreaker. The no voltage coilsfor three phase circuits are con-nected in A by means of bind*ing posts A. B. C and D on theface of the base, and from theA and B of the no voltage coils,connections are made…
