Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 193
, the full line (DE)representing the commu- A tating plane of the gener-ator and the dotted line(FG) representing thecommutating plane of themotor. The conductors inthe double angle (29) onone side of the armaturecan be thought of as beingin series with the con-ductors in the angle (20)on the other… … THE DIRECT-CUREENT GENERATOR 183
Electrical engineering
