Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 275
with respect to the brush (B2). The magnetic 264 PEACTICAL APPLIED ELECTRICITY flux from the two north poles or into the two south poles isnot equal on account of armature reaction which crowds theflux into the forward pole. This results in the voltage betweenthe neutral brush and one main brush… … Pig. 221 the same number of parts as there are magnetic poles on themachine. The alternate division points of the armaturewinding are connected to one slip ring and the remainingdivision points to a second slip ring. A coil of low resistanceand high inductance, called a reactor, is connected to…
Electrical engineering
