Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 386
s of the secondary coilwhen there is no load on the transformer. When the sec-ondary coil is supplying a current, the terminal voltage dropson account of the (IsRs) drop and magnetic leakage. Thesedrops must be subtracted from the total e.m.f. induced inthe secondary coil, which gives the terminal… … Fig. 313 376 PRACTICAL APPLIED ELECTRICITY 1 coil, which combines with the no-load current (lo), giving thetrue primary current (I). 414. Types of Transformers.—Transformers may bedivided into two types, depending upon the arrangement ofthe coils and magnetic circuit, viz, (A) Core-type…
Electrical engineering
