Practical applied electricity; a book in plain English, for the practical man. Theory, practical applications and examples (1911)
Moreton, David Penn, 1882- · Chicago, The Reilly & Britton co · leaf 45
shows three resist-ances (Ri), (R2),and (R3),connected in series to theterminals of the battery(B). The current has onlyone path from the positive to the negative terminal of thebattery. These resistances may be of widely different valuesand composed of different materials, but the total… … B B Fig. 6 SERIES AND DIVIDED CIRCUITS 35 lecting the resistance of the connections and the internalresistance of the battery, will be 3 + 4 + 5—12 ohms. The above relation of the total resistance to the individualresistances can be shown by a hydraulic analogy. Supposethat in Fig. 7 (A), (B), and…
Electrical engineering
