Practical draughtsmen's work, with numerous engravings and diagrams (1903)
Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 116
ight asthe semicircle, and the width will be given by the projectionfrom plan. The curves themselves must be drawn very neatlyby hand, so that their outline may be precisely similar to theother outlines. Sometimes an expert draughtsman may be foundwho can put them in with the bow-pen, but… … MALf PLANJ Fig. 179.—Fluted Column. drawing, observe that the thickening of the curves is regulatedby the 45*^ set-square, which shows where the line alters itscharacter. . It should be remembered that, although the illustrationsare printed when they appear in this book, yet they were alloriginally…
Mechanical drawing
