ing miles, while by subdividing one ofthese divisions into eight equal parts, furlongs would berepresented. Here an actual length of half an inch is under-stood to represent one mile, and the map or plan would bedescribed as being drawn to a scale of half an inch to themile. Another way in which… … Fig. 191.—Scale -^^ho 1 in. = 880 ft. ; 6 in. = 1 mile. only 72 6V2 o the size of the real object it is intended to show.This sum y26V2^ ^s known as the representative fraction ofthe scale, and sometimes is used to indicate any particularscale instead of the previous expression. The value of scale…
