NG TO SCALE AND FREPABING MAPS. 125 Figs. 191 to 194 illustrate plans of streets, and thesedrawings show what the street would look like as seen froma balloon. All these are drawn to scale so that the lengthsand widths can be measured from the plan. Kerb-lines areusually represented by dotted…
