)roject the frontelevation (Fig. 216), then the side elevation (Fig. 217), backelevation (Fig. 218), and sections (Figs. 219 and 220). Whenfinished and inked in, the drawing may be coloured, carefully fol-lowing the directions given in the chapter dealing with that subject MAKING A DRAWING.
