he exact centre for the curve of 1^ in. radius to 60 PRACTICAL DRAUGHTSMENS WORK, .join the arm and the boss. It is important to note that the exactpoint of meeting of the two curves will be at c in the line aj^joining their centres ; and of the curve and straight line at k^where a perpendicular… … Fig. 97.—Example Eequiring Accurate Drawing. The study of practical geometry forms a very good ground-work for a draughtsman, and in machine drawing is quite indis-pensable ; but for architectural drawing there is a great deal thatmay be omitted. One of the advantages pertaining to it is thatit…
