The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing. (1857)
Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Johnson, William, 1823-1864 · New York : Stringer & Townsend · leaf 200
t the side; butto prevent the point of the screw from injuring thebar, a loose plate of metal is interposed next to thebar, as shown in the section, fig. 24. The socket,M, is in a solid piece with its pen, or pencil-holder ; but the centre leg, n, is in a separatepiece from its socket, m, and is… … horizontal screw passage, or nut, to receive the screw spindle,I, which is held by an eye at the end of the socket groove,and is actuated by means of a button on tlic outside. By 190 THE PRACTICAL DRAUGHTSMANS turning the screw, i, in either direction, the centre leg may beadjusted with great…
Mechanical drawing
