The practical draughtsman's book of industrial design, and machinist's and engineer's drawing companion: forming a complete course of mechanical, engineering, and architectural drawing (1854)
Armengaud, aîné (Jacques-Eugène), 1810-1891, Armengaud, Charles A., 1813-1893, Amouroux, Jules, Cory, William Johnson, 1823-1892 · New York, Stringer & Townsend · leaf 106
.—The points of this curve may also be determinedby drawing, with the centre, c, arcs passing through the points ofdivision, a, V, c, d\ and cutting the arcs described with the variouscentres, o, o1, o2, o3, in a, b2, c2, d2, which are so many points in theepicycloid. 3d Solution.—The curve may… … I Petitcolin iculn |Wellj.Ka , \i memyaud 8c Vmouroux Practical Draughtsman Plate 18.
Decorative arts · Drawing
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
