^ found.To unite two inclined straight lines by an arc tangent to both, radius given. Prolongthe given lines to meet at a (Fig. 68). With a as a centre andthe given radius describe the arc m n. Parallels to the given lines andtangent to arc m n meet at d, from which perpendiculars to the givenlines…
