the shaking-force atthe crank-angle aoOai. Its horizontal component is evidently thesum of Oci and a\Alt a0A0 and a6A6 are equal to HI and 5Jrespectively to the new scale (Fig. 205.) Suppose counterweights are added in such manner that theircentrifugal force is equivalent to a force b20 acting at… … Fig. 221. eating parts. The amount of these alterations is evident whenwe join b\ and A\, b2 and A2, etc. For the previous shaking-forceOA\ is now to be combined with the introduced force b\0, and theresult is a shaking-force b\A\t OA2 is to be combined with b20,giving b2A2. Lay off OBi, OB2, etc.,…
