Practical engineering drawing and third angle projection, for students in scientific, technical and manual training schools and for ... draughtsmen .. (1897)
Willson, Frederick Newton, 1855-1939 · Princeton, N.J., The author · leaf 40
nd a given circle. Four solutions. (6) Circle through a given point and tangent to two given■circles. Four solutions. (7) Circle tangent to three straight lines, two only of which may be parallel. Four solutions. (8) Circletangent to two straight lines and a given circle. Four solutions. (Art. 105,… … intersection of two lines. Join the given point e with any point ,/ on A B and also with some pointg on CD. From anj point h on A B draw h i parallel to / g, then i k parallel to g e and h kparallel to f e. The line k e will fulfill the conditions. ~4. To drmo an oval upon a given line. Describe a…
Mechanical drawing · Lettering
