Practical engineering drawing and third angle projection, for students in scientific, technical and manual training schools and for ... draughtsmen .. (1897)
Willson, Frederick Newton, 1855-1939 · Princeton, N.J., The author · leaf 90
ations of the construction justdescribed which will become evident on careful inspection. TINTING. —BRUSH SHADING. 83 231. Fig. 132 is a Minton design with which many are famihar, and which affords opportunityfor considerable variety in finish. Its construction is almost self-evident. The equal… … The octagons may be in Prussian blue, the hexagons in carmine, and the remainder in whiteand black, as shown; or browns and drabs may be employed for more subdued effects. SHADING. 232. For shading, by graduated tints, provide a glass of clear water in addition to the tint;also an ample supjily of…
Mechanical drawing · Lettering
