Practical engineering drawing and third angle projection, for students in scientific, technical and manual training schools and for ... draughtsmen .. (1897)
Willson, Frederick Newton, 1855-1939 · Princeton, N.J., The author · leaf 91
of the higher office buildings of ourgreat cities. By drawing first an end view of a Phoenix column, similar tothat of Fig. 135, we can readily derive an oblique view like that ofthe jjlate, by including it between parallels from all points of theformer. The ijroportions of the columns are… … MATERIALS OF CONSTRUCTION. 85 In a later chapter the proportions of other forms of structural iron will be found. Short lengths of any of these, if shown in oblique view, are good subjects for thebrush, especially for dry shading, the effect to be aimed at being thatof the rail section of Fig. 136.…
Mechanical drawing · Lettering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
