Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 150
z^r^r—^ • … Fig. 8. The Junker Two Stroke Cycle Engine. piston P2, I-I the side rods of the piston P2, and V is the threethrow crank shaft which is acted on by the three connectingrods H-H-G. The piston P2 is connected to the side rodsthrough the yoke Y. It will be noted that the crank throws 146 GAS, OIL AND…
Internal combustion engines · Traction-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
