Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 571
evel through the bottom panels of thedoors and lower pilasters ; another sectionshould be given at a level of the upper cornice of pediment, the tympanum, and thehorizontal cornice, showing the relation ofthis with the pediment, etc. Whole eleva-tions, or at least halves, drawn full size,and in… … Fig. 1728.—Enlarged Horizontal Section through Lower Pilasters and Panels. pilasters and glass panels of doors, similarto section Fig. 1727. It would be veryconvenient to have a third horizontalsection taken through the frieze. Probablythe best plan would be to have the rodsufficiently wide, so…
Carpentry · Joinery
