Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 185
Fig. 76. De La Vergne Spray Nozzle. The air and oil enter the nozzle at opposite sides of thecylinder B which fits snugly into the valve body A. As theair and oil proceed side by side along the outside of B, theyare forced to pass through a series of chambers connectedby a system of fine diagonal…
Internal combustion engines · Traction-engines
