Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 268
Magneto of Roberts Motor in Advanced Position. will, therefore, be seen that the breaker ordinarily short-circuitsthe low tension winding and that this short-circuit is biokenonly when the breaker opens; it will also be apparent that when … 112-a. Advance and Retard Mechanism Used in the Roberts Motors.The Magneto is Driven by a Helical Gear from the Small Pinion.By Shifting the Gear Back and Forth on the Pinion, the Armatureof the Magneto is Advanced or Retarded in Regard to the PistonPosition. The Reason for this Change Will be Seen…
Internal combustion engines · Traction-engines
