Practical hand book of gas, oil and steam engines, stationary, marine, traction; gas burners, oil burners, etc.; farm, traction, automobile, locomotive; a simple, practical and comprehensive book on the construction, operation and repair of all kinds of engines (1916)
Rathbun, John B. [from old catalog] · Chicago, Charles C. Thompson co · leaf 72
ank chamber when the piston is on its upward stroke. Thisvacuum drags against the piston and absorbs a considerableamount of power until the piston reaches the upper end ofthe stroke. At this point the inlet port is opened and thevacuum is broken by the rush of the mixture through the in-let port.… … Elevation of Fairbanks-Morse Three-Port Two Stroke Marine Motor Show-ing Warming Device for Carburetor Air. STROKE 1. In Fig. 6, the piston is shown at the end of thecompression stroke with ignition taking place in the combustionchamber C. The pressure due to the expansion drives the pistondown on…
Internal combustion engines · Traction-engines
