re compressed). St k ^ 1 Ignition. * | Expansion (working stroke). Stroke 4. Exhaust—(Scavenging stroke). These events with the pressures incident to each drawn tosome relative scale are shown graphically in Fig. 10 by fourlines representing the four strokes of the piston. In order toshow the… … Figs. 10-11-12. Showing Respectively a Typical Four Stroke Diagram,Retarded Combustion and Retarded Spark. GAS, OIL AND STEAM ENGINES 75 is the scale of pressures (somewhat exaggerated in order thatthe small vacuum and scavenging pressures shall be clearlyshown). The line marked atmosphere…
