Practical instructor and reference book for locomotive firemen and engineers: a practical treatise .. (1916)
Lockhart, Charles F. (Charles Fulton), b. 1872 · New York, The Norman W. Henley publishing co. · leaf 151
ded with one consolidatedsafety valve set to open at a pressure of 22c pounds. 447. The combustion chamber is entirely unobstructedand is provided with a manhole, so that it may beeasily entered. The tube ends are thus readily ac-cessible. 448. The combustion chamber is surrounded by aseparable… … opq 9 MALLET ARTICULATING COMPOUND 149 entire design is so arranged that the locomotive can bereadily separated into two sections. The dome is made of cast steel and is placed immediatelyabove the high-pressure cylinders. 450. The throttle valve is of the usual balanced type andcommunicates…
Locomotives
