Fig. 20.—Detroit Lubricator, Side Sectional View. valve in it as shown in Figs. 23 and 24; while the otherkind simply has a small hole about the size of a needledrilled through it. Should this hole become stopped up, LUBRICATOR DEFECTS 99 the lubricator will continue to feed until the tallow pipe… … C C C Fig. 21.—Nathan Bulls Eye Lubricator. when the valves and cylinder become dry. This troubleis seldom experienced with the ball valve plug. 304. It has become the practice on most roads to takethe choke plugs away from the lubricators, where they were iOO LUBRICATOR DEFECTS formerly located,…
