Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 29
Fig. 52—Psrramid. Fig. 53—Cylinder. A cylinder is a solid figure described by therevolution of a rectangular or parallelogram aboutone of its sides—^Fig. 53, 26 MECHANICAL DRAWING The axis of a cylinder is the fixed straight lineabout which the parallelogram revolves. The ends of a cylinder are the…
Mechanical drawing · Machine design
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
