find the length of an arc of a circle^—Fig. 64.Divide the chord AC of the arc into four equalparts as shown. With the.radius AD equal toone-fourth of the chord of the arc and with A asthe center describe the arc DE. Draw the line EGand twice its length will be the length of the arcAEC. To draw… … Fig. 65.
