In the kind of coup-ling shown in Fig. 157 a cast iron center or bossprovided with a flange is secured to the end ofeach shaft by a sunk key driven from the faceof the flange. These flanges are then connected bybolts and nuts. To ensure the shafts being in line the end of oneprojects into the…
