Practical mechanical drawing and machine design self taught .. (1907)
Westinghouse, Charles. [from old catalog] · Chicago, F. J. Drake & co. · leaf 97
Fig. 18Q-^§team Ingijie Governor, 94 MECHANICAL DRAWING base A within the limits of the upright K. Dand E are carried by the clamp H, which embracesthe upright K. By turning the milled nut J thescriber is fixed in position in relation to K. A … fine vertical adjustment is obtained by rotatingthe milled nut B. After all adjustments have beenmade, K is locked in position by the set-screw C.Example 18. Jack Screw. From the half eleva- 13 H- zYz- Tig. 181—Details
Mechanical drawing · Machine design
