Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 320

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 320
X-A \\ /-- V. … /, 306 PRACTICAL SOLID GEOMETRY chai\ 262. Problem.—To draw the plan of a cube, havinggiven the length of edge, the inclination e of one face, andthe inclination 9 of a diagonal of the solid. (No figure.) There are three preliminary problems to be worked. 1. Find the length of the diagonal. 2. Find…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
