Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 360

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 360
ethod.—The tangent plane at Pis perpendicularto SP, hence its traces are perpendicular to sp and sp re-spectively. To determine these traces draw pc perpendicular to spand/V parallel to xy; then PC is a horizontal line passingthrough P, contained by the tangent plane and having Cin its vertical… … 346 PRACTICAL SOLID GEOMETRY chap. 289. Problem. — A given cylinder, axis AB, lies witha generator on the horizontal plane. It is required todetermine the plane which shall touch the cylinder at apoint whose plan p is given. Let the rectangle cdefbe the given plan of the cylinder. First…

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
