Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus (1899)

Harrison, Joseph, Baxandall, George Albert · London Macmillan · leaf 76

An illustration from Practical plane and solid geometry for advanced students, including graphic statics, adapted to the requirements of the South Kensington syllabus, 1899, leaf 76
D aregiven, their point of intersection being inaccessible. Itis required to describe a circle which shall touch theselines and pass through a given point P. By Prob. 22, draw FF to bisect the angle between AB and CD.With any centre O in EF, draw the circle which touches AB. By Prob. 24, draw PQ to… … 62 K

Geometry, Descriptive -- Problems, exercises, etc · Geometry, Plane -- Problems, exercises, etc · Graphic methods

Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
