The practical telephone handbook and guide to the telephonic exchange (1906)
Poole, Joseph · New York, Macmillan Co. · leaf 198
by the raising of the jack springs from the inner springs. Thedrop of. the calling line serves as the ring-off or clearing signal,being connected as a shunt to the main loop-line circuit. Thedrops are wound to 1000 ohms, and, being of high inductance,they offer great impedance to the speaking… … Elevation Fig. 197 Fig. 198 line, the required number ascertained, and the plug with-drawn and plugged into the called-for line-jack. A ring is 174 PRACTICAL TELEPHONE HANDBOOK then given, and on an answer being obtained the plug of thecalled line is inserted into the jack of the calling line,…
Telephone
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
