to the ordinary one made by the turning of the weft thread ; but where great strength is not required it makes a very good substitute. It is formed by a very simple process, illustrated by figs. 51 and 52. They show the shed formed by the leaves of heddles A and B and the looping heddle C. One… … flying heddle which is attached to the front leaf. Fig. 51 shows the position of these threads when the front leaf is sunk, and fig. 52 w^hen the back leaf is sunk. Fig. 53 is an enlarged view of the selvage itself, showing how the threads are bound together. By a careful examination of
