A practical treatise on the construction of the power-loom and the art of weaving : all descriptions of texture produced by leaves of heddles : illustrated with diagrams, with calculations and instructions for the production of cotton, woollen, linen, and jute fabrics : intended as a textbook for those engaged in the trade (1887)

Brown, Alex (Alexander) · Dundee : James P. Mathew & Co. ; London : Simpkin, Marshall, & Co. · leaf 29

An illustration from A practical treatise on the construction of the power-loom and the art of weaving : all descriptions of texture produced by leaves of heddles : illustrated with diagrams, with calculations and instructions for the production of cotton, woollen, linen, and jute fabrics : intended as a textbook for those engaged in the trade, 1887, leaf 29
PRINCIPAL PARTS OF THE LOOM. ' 25 centre, which requires a momentum in another part of the loom to carry it over that point. This must be avoided as far as possible, as the less momentum the loom can be Fig. 2. … wrought with the less will be the breakage caused by the action of the protectors. The broader the loom the more eccentric its move- ments.—The broader the loom is the greater must be the
