A practical treatise on the steel square and its application to everyday use : being an exhaustive collection of steel square problems and solutions, "old and new", with many original and useful additions, forming a complete encyclopedia of steel square knowledge, together with a brief history of the square, and description of tables, keys and other aids and attachments (1903)

Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Riverside, Ill. : Radford Architectural Co. · leaf 198

An illustration from A practical treatise on the steel square and its application to everyday use : being an exhaustive collection of steel square problems and solutions, "old and new", with many original and useful additions, forming a complete encyclopedia of steel square knowledge, together with a brief history of the square, and description of tables, keys and other aids and attachments, 1903, leaf 198
^-inch run, and that ahip for a i-foot run of the building becomes acommon rafter for a 17-inch run. Therefore,the rule that applies to the common rafter also … Fig. i- applies to the hip rafter, i.e., the run and risetaken on the square will give the seat and plumb 196 PRACTICAL USES OF cuts. The run and length of the rafter taken onthe square will give the side cuts, or taking thescale for a i-foot run, Fig. 146, it is 12 on thetongue and the rise on the…

Carpenters' squares · Architecture, Domestic · Equerre de charpentier
