A practical treatise on the steel square and its application to everyday use : being an exhaustive collection of steel square problems and solutions, "old and new", with many original and useful additions, forming a complete encyclopedia of steel square knowledge, together with a brief history of the square, and description of tables, keys and other aids and attachments (1903)
Hodgson, Fred. T. (Frederick Thomas), 1836-1919 · Riverside, Ill. : Radford Architectural Co. · leaf 65
ion with the square, makes theobtaining of the angle-joints for anv kind of apolygon quite an easy matter. This diagramrequires no explanation, as the direction of thelines shows how the joints are found. The linesare also laid off in degrees, enabling the oper-ator to make use of the lines or… … POLYGONS AND THEIR MITERS. Bf A ^ Wooos author or t«c squav .^oot dciIncator inTHE ART OF fRAMING Fig. 31 THE FENCE The first thing required in connection with thesquare is a fence. This is a simple affair andmay be of wood or of metal according to the THE STEEL SQUARE 63 taste or wealth of the…
Carpenters' squares · Architecture, Domestic · Equerre de charpentier
