turning Perpendicular Faces. with much ease and freedom. When turning down aperpendicular face with this corner, either for finish-ing its surface, or for parting off, the chief difficulty isto cut the face true ; it is apt to become slightly wavy.The remedy is to keep the chisel well sharpened,… … Fig. 92. Side Tool. Turning in the cup chuck, or bell chuck, is done insteadof turning between centres,when a recess has to be boredin the front end of the work,which could not be done if itwere centred upon the backpoppet; or when a number ofsmall articles have to be turnedand cut off in…
