Principles and practice of electrical engineering (1914)
Gray, Alexander, 1882-1921 · New York [etc.] McGraw-Hill Book Company, inc. · leaf 111
Fig. 107.—Connec-tions of a shunt motorduring starting. … Fig. 108.—Starter fora shunt motor. Fig. 109.—Starterwith a no-voltage re-lease. the armature current = the total current — the exciting current= 77 - 2 = 75 amp. applied voltage the total resistance at starting full-load armature current HO , ,- ,-=k = 1.47 ohms. the starting resistance = the…
Electrical engineering
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
