Principles and practice of electrical engineering (1914)
Gray, Alexander, 1882-1921 · New York [etc.] McGraw-Hill Book Company, inc. · leaf 203
ing T and t\ is then equal to r2, i\ isequal to i2, diagram A, and no current flows in the coil F, so thatthe exciter voltage and the booster voltage are both zero. If the generator load increases, the pull on r\ increases and itsresistance decreases and is now less than r2 so that i\… … 0 1 2 3 4 5 6 78 9 10 Minutes Fig. 197.—Load curves on the power house of a steel mill. If the generator load now becomes less that normal, the pull onrx decreases and its resistance increases and is now greater thanr2 and current now flows in the coil F in the direction of i2, thebooster voltage…
