I has its minimumvalue. When the handle is in the position Hi, current flowsthrough the path TcdebQ so that the resistance between a ande has been cut out. As the handle is moved further over, theresistance in the circuit is further decreased until finally, whenthe handle is in the position Hi, the… … Fig. 30.
