e phase. Dismantled parts listed below. 1. Stator frame. 2. Complete rotor. 3. Shields. 4. Journal boxes. 5. Oil rings. 6. Stator winding. 7. Statorleads. 3. Cable tips for leads. 9. Oil gauge. 10. Oil hole cover. 11. Shaft. 12. Pole shoe. 13. Collector ring. 14. Field coil. 15. Cap screws for… … 70. Magnetic Circuit.—It is important to get an understand-ing of the magnetic path in an electric machine. Various shapesare possible, but an understanding of one makes all others easy.Fig. 100 is a diagram indicating the parts of a typical mag-netic circuit, with their names. It is not intended…
