tance R is inserted in the plate lead, inseries with the plate battery Er>, then the only values of e? and»p which can exist when the tube is operating are given by theequation ev=E\>—Rip, where E* and R express the character-istics of the equipment used in connection with the plate oroutput… … fatvt/iiuj w Quajjno djVU externally placed between the filament and plate of the tube.If the grid voltage, for example, is —10, then the plate voltagewill be 220 volts and the plate current 16 milliamperes, as de- 466 ELECTRON TUBES. termined in Fig. 2G1 by the intersection of the dotted line…
