Hague, Charles Arthur · New York : McGraw Publishing Company · leaf 183
jacketed, packed around their outside barrels withmineral wool, and lagged with black walnut; the receiver isalso covered with non-conducting material and lagged to. cor-respond with the steam cylinders. The water of condensa-tion from the steam jackets and receiver was discharged throughtraps… … Fig. 35.—Reynolds Three Cylinder Compound Pumping Engine. REYNOLDS TRIPLE EXPANSION PUMPING ENGINE 149 valves for each plunger, and right here comes in an illustra-tion of how satisfactory permanent results are sometimes ob-tained in trying to escape from a difficulty which has presenteditself. The…
Pumping machinery
