Radford's architectural drawing : complete guide to work of architect's office, drawing to scale--tracing--detailing--designing --classic order of architecture. A complete and thorough course, clearly written and beautifully illustrated; suited alike to individual study and class instruction (1912)
Radford, William A., 1865- · Chicago, The Radford Architectural Company · leaf 114
Tig. 51. Erroneous Method. Fig. 52. Correct Method.Framing of Posts and Girders to Counteract Effects of Shrinkage.
Architectural drawing · Architecture
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
