Radford's architectural drawing : complete guide to work of architect's office, drawing to scale--tracing--detailing--designing --classic order of architecture. A complete and thorough course, clearly written and beautifully illustrated; suited alike to individual study and class instruction (1912)
Radford, William A., 1865- · Chicago, The Radford Architectural Company · leaf 145
re-sented by the shadow they produce, there beingno definite line for the edge of the roof. Forthe corners of the buHding, there is not a hard,sharp line, but a broken, irregular line. The 302 AECHITECTURAL DRAFTING doors and windows are all represented by theshadows they cast. It will be noticed…
Architectural drawing · Architecture
